XTDB 2.x Early Access

XTDB is a bitemporal and dynamic relational database for SQL and Datalog.

XTDB 2.x is still work-in-progress and currently unreleased software (alpha release coming soon!). Current documentation:

Want to try it quickly right now?

Scroll down to find out how below!

About 2.x Early Access

This 2.x Early Access programme provides visibility for users who are interested in the broad future of XTDB. Developing in the open allows us to process feedback faster and deliver on our promises sooner. This also means that many things we intend to implement or fix prior to General Availability (or even an alpha release) will currently produce opaque error messages, undocumented bugs, and a generally unreliable experience. Please be forgiving!

XTDB 1.x will remain supported for the foreseeable future - we will continue to triage 1.x issues and provide releases well beyond 2.x General Availability.

Early Access will continue until we are satisfied that the performance and deployment of 2.x is robust enough to recommend for production usage. This will require closely collaborating with partners and users who are prepared to test and give feedback on our bleeding edge changes. Interested to help? Get in touch!

Key Features of XTDB 2.x

Cloud native: modern columnar architecture built around Apache Arrow and commodity object storage.
Bitemporal: all data is accurately versioned as updates are made (system time), and all data exists within a universal domain timeline for representing 'validity'/'effectivity' (valid time).
Dynamic: no upfront schema needs to be specified before records can be inserted. Complex and nested data is automatically represented using Apache Arrow types.
Relational: the full spectrum of traditional SQL database capabilities is available - including joins, transactions, bag/multiset semantics, three-valued logic, multiple N-ary relations etc.
SQL: unrestricted accessibility for a mainstream audience and an eye to the future with preliminary Flight SQL driver support.
Datalog: programmer-friendly API for complex relational querying that overcomes many of SQL’s compositional challenges.

Check out our detailed What is XTDB breakdown to learn more about what makes XTDB special. ✨

Things you can try right now:

Feel free to mix and match the SQL and Datalog snippets - they're interoperable!

If you have any issues with these specific examples, please let us know: hello@xtdb.com

Install

Via Docker or as a JVM library

;; deps.edn
{:mvn/repos {"ossrh-snapshots" {:url "https://s01.oss.sonatype.org/content/repositories/snapshots"}}
 :deps {org.clojure/clojure {:mvn/version "1.11.1"}
        com.xtdb.labs/xtdb-api {:mvn/version "2.0.0-SNAPSHOT"}
        com.xtdb.labs/xtdb-core {:mvn/version "2.0.0-SNAPSHOT"}
        com.xtdb.labs/xtdb-http-server {:mvn/version "2.0.0-SNAPSHOT"}
        com.xtdb.labs/xtdb-pgwire-server {:mvn/version "2.0.0-SNAPSHOT"}}
 ;; needed on JDK16+
 :aliases {:xtdb {:jvm-opts ["--add-opens=java.base/java.nio=ALL-UNNAMED"
                             "-Dio.netty.tryReflectionSetAccessible=true"]}}}

;; Once you have a REPL (started with clj -A:xtdb if you’re on JDK 16+), you can create an in-memory XTDB node with:
(require '[xtdb.node :as xt.node]
         '[xtdb.api :as xt])

(def my-node (xt.node/start-node {:xtdb/server {:port 3001}
                                  :xtdb/pgwire {:port 5432}}))

;; Confirm this API call returns successfully
(xt/status my-node)

# Use this one-line shell command to start a Clojure REPL + XTDB server:
clojure -Sdeps '{:mvn/repos {"ossrh-snapshots" {:url "https://s01.oss.sonatype.org/content/repositories/snapshots"}}
                 :deps {org.clojure/clojure {:mvn/version "1.11.1"}
                        com.bhauman/rebel-readline {:mvn/version "0.1.4"}
                        com.xtdb.labs/xtdb-api {:mvn/version "2.0.0-SNAPSHOT"}
                        com.xtdb.labs/xtdb-core {:mvn/version "2.0.0-SNAPSHOT"}
                        com.xtdb.labs/xtdb-http-server {:mvn/version "2.0.0-SNAPSHOT"}
                        com.xtdb.labs/xtdb-pgwire-server {:mvn/version "2.0.0-SNAPSHOT"}}
                 ;; needed on JDK16+
                 :aliases {:xtdb {:jvm-opts ["--add-opens=java.base/java.nio=ALL-UNNAMED"
                             "-Dio.netty.tryReflectionSetAccessible=true"]}}}' \
        -M -e '(do (require (quote [xtdb.node :as xt.node])
                            (quote [xtdb.api :as xt])
                            (quote [rebel-readline.main]))
                   (def my-node (xt.node/start-node {:xtdb/server {:port 3001}
                                  :xtdb/pgwire {:port 5432}}))
                   (rebel-readline.main/-main))' -r

# Boot the 2.x Early Access Docker image in seconds.
docker pull ghcr.io/xtdb/xtdb-ea
docker run -p 5432:5432 -p 3001:3000 ghcr.io/xtdb/xtdb-ea

Clojure (deps.edn) Clojure (1-liner) Docker

Connect

Via either (1) HTTP Clojure client driver, (2) experimental SQL-only pgwire-server compatibility, or (3) use the embedded node started via your Clojure REPL (i.e. skip this step)

;; deps.edn
{:mvn/repos {"ossrh-snapshots" {:url "https://s01.oss.sonatype.org/content/repositories/snapshots"}}
 :deps {org.clojure/clojure {:mvn/version "1.11.1"}
        com.xtdb.labs/xtdb-api {:mvn/version "2.0.0-SNAPSHOT"}
        com.xtdb.labs/xtdb-http-client-clj {:mvn/version "2.0.0-SNAPSHOT"}}}

;; Once you have a repl started ...
(require '[xtdb.client :as xt.client]
         '[xtdb.api :as xt])

(def my-node (xt.client/start-client "http://localhost:3001"))

(xt/status my-node)

# Use this one-line shell command to start a Clojure REPL
# It connects to your XTDB container automatically:
clojure -Sdeps '{:mvn/repos {"ossrh-snapshots" {:url "https://s01.oss.sonatype.org/content/repositories/snapshots"}}
                 :deps {org.clojure/clojure {:mvn/version "1.11.1"}
                        com.bhauman/rebel-readline {:mvn/version "0.1.4"}
                        com.xtdb.labs/xtdb-api {:mvn/version "2.0.0-SNAPSHOT"}
                        com.xtdb.labs/xtdb-http-client-clj {:mvn/version "2.0.0-SNAPSHOT"}}}' \
        -M -e '(do (require (quote [xtdb.client :as xt.client])
                            (quote [xtdb.api :as xt])
                            (quote [rebel-readline.main]))
                   (def my-node (xt.client/start-client "http://localhost:3001"))
                   (rebel-readline.main/-main))' -r

# Use any Postgres-compatible client.
psql -h localhost

Clojure (deps.edn) Clojure (1-liner) psql

Instant Schemaless Writes

XTDB does not require any pre-defined schema or tables. Every insert, update, and delete is immutable.

(xt/submit-tx my-node [[:put :posts {:xt/id 1234
                                     :user-id 5678
                                     :text "hello world!"}]])

(xt/q my-node '{:find [text]
                :where [($ :posts [text])]})

INSERT INTO posts (xt$id, user_id, text)
  VALUES (1234, 5678, 'Hello World!');

SELECT posts.text FROM posts;

Datalog (Clojure) SQL

First-Class Nested Data

Relational querying for messy data.

;; XTDB has always handled ~arbitrary data well - just smash your maps in!
(xt/submit-tx my-node [[:put :people {:xt/id 5678
                                      :name "Sarah"
                                      :friends [{:user "Dan"}
                                                {:user "Kath"}]}]])

;; Datalog now supports first-class nested lookups too:
(xt/q my-node '{:find [friend]
                :where [($ :people [friends])
                        [(nth friends 1) friend]]})

-- Nested data is natural!
-- XTDB SQL makes working with Arrays and Objects easy,
-- these are not opaque or limited JSONB types,
-- instead they are seamlessly integrated with SQL:
INSERT INTO people (xt$id, name, friends)
  VALUES (5678, 'Sarah',
          [{'user': 'Dan'},
           {'user': 'Kath'}]);

SELECT people.friends[2] FROM people;

Datalog (Clojure) SQL

Native Bitemporality

No more maintaining your own timestamp columns for soft-delete, versioning or audit requirements.

;; Datalog uses as-of-now defaults
;; To view the entire history of a record:
(xt/q my-node '{:find [person
                       valid-from valid-to
                       system-from system-to]
                :where [($ :people [{:xt/id 5678
                                     :xt/* person
                                     :xt/valid-from valid-from
                                     :xt/valid-to valid-to
                                     :xt/system-from system-from
                                     :xt/system-to system-to}]
                                   {:for-valid-time :all-time
                                    :for-system-time :all-time})]})

-- XTDB SQL defaults to the SQL:2011 standard
-- using 'SET VALID_TIME_DEFAULTS TO ISO_STANDARD;'
-- this means that all of time visible by default
-- but it also offers alternative defaults for a more intuitive experience:
SET VALID_TIME_DEFAULTS TO AS_OF_NOW;

SELECT *
FROM people
         FOR ALL SYSTEM_TIME
         FOR ALL VALID_TIME
         AS x (xt$id,
               name,
               friends,
               xt$valid_from,
               xt$valid_to,
               xt$system_from,
               xt$system_to);

Datalog (Clojure) SQL

Cross-Time Queries

Time in XTDB is optional – but universal. Advanced applications can even query time itself.

(xt/submit-tx my-node [[:put :posts
                             {:xt/id 9012 ;; original post
                              :user-id 5678
                              :text "Happy 2019!"}
                              {:for-valid-time
                               [:in #inst "2019-01-01" nil]}]
                       [:put :posts
                             {:xt/id 3456 ;; later post
                              :user-id 5678
                              :text "(New) Happy 2024!"}
                              {:for-valid-time
                               [:in #inst "2024-01-01" nil]}]
                       [:put :posts
                             {:xt/id 9012 ;; original post again
                              :user-id 5678
                              :text "Edited-2019-post: Happy 2025!"}
                              {:for-valid-time
                               [:in #inst "2025-01-01" nil]}]])

(xt/q my-node '{:find [text]
                :where [($ :posts [text]
                                  {:for-valid-time
                                   [:at #inst "2025-01-02"]})]})

(xt/q my-node '{:find [text]
                :where [($ :posts [text])]})

;; what other (versions of) posts were valid during the same time range as the 2019 post?
(xt/q my-node '{:find [text]
                :where [($ :posts [{:xt/id 3456
                                    :xt/valid-time vt}]
                                  {:for-valid-time :all-time})
                        ($ :posts [{:xt/id other-id
                                    :xt/valid-time other-vt} text]
                                   {:for-valid-time :all-time})
                        [(<> other-id 3456)]
                        [(overlaps? vt other-vt)]]})

INSERT INTO posts (xt$id, user_id, text, xt$valid_from)
  VALUES (9012, 5678, 'Happy 2019!', DATE '2019-01-01'),
         (3456, 5678, '(New) Happy 2024!', DATE '2024-01-01'),
         (9012, 5678, 'Edited-2019-post: Happy 2025!', DATE '2025-01-01');

SELECT posts.text FROM posts
  FOR VALID_TIME AS OF DATE '2025-01-02';

SELECT posts.text FROM posts;

SELECT P2.text
FROM posts FOR ALL VALID_TIME AS P1,
     posts FOR ALL VALID_TIME AS P2
WHERE P1.xt$id = 3456
  AND P2.xt$id <> 3456
  AND P1.VALID_TIME OVERLAPS P2.VALID_TIME;

Datalog (Clojure) SQL

Native Apache Arrow

XTDB embraces Apache Arrow both internally and externally.

SELECT more_posts.text
  FROM ARROW_TABLE('https://xtdb.com/more_posts.arrow')
  AS more_posts;

;; Coming soon!

SQL Datalog - Coming Soon!

Complete Erasure

To comply with privacy laws, erasure is necessary when handling immutable data.

;; we are going to rename :evict to :erase in the near future
(xt/submit-tx my-node [[:evict :people 5678]])

ERASE FROM people WHERE people.xt$id=5678;

Datalog (Clojure) SQL

What next?

Why not Learn Datalog Today! Or generate your own playground starter project using our Clojure templates!

New for 1.x users

The 2.x design expands on the essential qualities of 1.x and provides significant new capabilities:

“Cross time” queries, e.g. temporal joins and temporal range scans - where 1.x is optimized only for point-in-time queries
Massive and affordable scale via a separated storage and compute architecture, using object storage for handling large chunks of Apache Arrow data on demand
Extensive relational algebra optimizations (e.g. subquery decorrelation)
First-class SQL experience alongside Datalog with an entirely new SQL parser and planner (no longer using Apache Calcite)
Organize records into tables for performance (query planning, partitioning etc.), introspection, and seamless SQL interoperability
Datalog enriched with SQL-derived functionality, with a SQL-based core library, “Bag” / “multi-set” semantics, and Three-Valued Logic (3VL) - supersedes 1.x Clojure classpath interop

The roadmap towards General Availability

This roadmap is an expression of intent and is subject to change.

Additional storage backends: a full suite of cloud storage adapters optimized for various Kafka-like and S3-like managed services
Monitoring: database health, OpenTelemetry
Deployment: zero-configuration Kubernetes setup for managed platforms (i.e. EKS/AKS/GKS)
Tiered caching: block management, clustering
Content indexing: light & adaptive indexes
Benchmarking: fine-tuning against AuctionMark, TPC-H and beyond
Hardening: transaction processing, execution engine compilation, complex Arrow usage
Join planning: additional statistics (e.g. HyperLogLog, histograms)
Language drivers: e.g. Java & Kotlin
SQL drivers: evolved pgwire-server support (currently all data is returned as JSON), dynamic Flight SQL
API Completeness - for example:
- INFORMATION_SCHEMA: users should be able introspect all data and aspects of the database as built-in virtual tables through the primary query APIs. e.g. an initial version of the `xt$txs` table is already implemented (Change Data Feed functionality to follow)
- User-definable transaction metadata: improved provenance, "Event sourcing without the hassle"
- Database VIEWs: gradual schema, writeable views, nested views, materialized views
- Batch writes: concurrent & atomic bulk loading of data
- Pull-like API: nested data retrieval that is more ergonomic than scalar subqueries
- Ongoing SQL enhancements: e.g. implement additional ISO specification functions and operators

XTDB Cloud Service?

Are you eagerly waiting for our announcement of v2.x as a usage-based cloud service? Join the waiting list here.

Want to chat?

Get in touch! hello@xtdb.com
